Profile Projector [GP] for projection of gobos on a surface.
Spherical and aspherical, double flat convex lens system. Aperture angle ranges from 12-16°.
Gobo size G. Gobo outside diameter 66 mm, max printable area d = 48 mm. WE-EF recommends d = 38 mm.
IP66. Class I. IK07. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass main lens. One cable gland, second gland for through wiring on request. PMMA LED lens array. Integral driver, thermally separated. Factory-installed LED circuit board. LED board can be removed for upgrading.
Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately.
Example: XXX-XXXX-9004 (Black)
+ XXX-XXXX (Accessory 1)
Eigenschaften
Material
Gehäuse
Marine-grade, die-cast aluminium alloy
Schrauben
PCS Polymer Coated Stainless Steel Hardware
Farben
Pending
Dichtung
Silicone CCG® Controlled Compression Gasket
Schlagfestigkeit
IK07
Schutzart
IP66
Abdeckung
Korrosionsschutz
5CE
Befestigung
Elektrik
LED Treiber
Integral EC electronic converter in thermally-separated compartment
Kabel
Leistungsfaktor
> 0.9
Netz
Integral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
Überspannungsschutz
Integral 10kV Surge Protector
Weitere Eigenschaften
Lifetime
Ta=25°/40° L70B50 > 50000h
----
Lichtverteilung
Lichtstrom (lm)
Farbtemperatur (K)
Artikelnummer
Lichtverteilung
Lichtquelle
Bemessungslichtstrom
CRI
Vorschaltgerät
Gewicht (kg)
Open Data (txt)
Datenblatt
IES, LDT, ULD
139-2128_min
symmetric Gobo-Projector [GP] - min aperture angle
LED-FT-24W (3000K)
987.4
80
electronic gear
18.08
139-2129_min
symmetric Gobo-Projector [GP] - min aperture angle
LED-FT-24W (4000K)
1030.1
80
electronic gear
18.08
139-2116_min
symmetric Gobo-Projector [GP] - min aperture angle
LED-FT-37W (3000K)
1339.3
80
electronic gear
18.08
139-2124_min
symmetric Gobo-Projector [GP] - min aperture angle
LED-FT-37W (4000K)
1396.3
80
electronic gear
18.08
139-2509_min
symmetric Gobo-Projector [GP] - min aperture angle
LED-FT-24W (2700K)
958.9
80
electronic gear
18.08
139-2512_min
symmetric Gobo-Projector [GP] - min aperture angle
LED-FT-37W (2700K)
1300.8
80
electronic gear
18.08
139-2509_max
symmetric Gobo-Projector [GP] - max aperture angle
LED-FT-24W (2700K)
990.3
80
electronic gear
18.08
139-2512_max
symmetric Gobo-Projector [GP] - max aperture angle
LED-FT-37W (2700K)
1343.5
80
electronic gear
18.08
139-2129_max
symmetric Gobo-Projector [GP] - max aperture angle
LED-FT-24W (4000K)
1063.9
80
electronic gear
18.08
139-2128_max
symmetric Gobo-Projector [GP] - max aperture angle
LED-FT-24W (3000K)
1019.7
80
electronic gear
18.08
139-2124_max
symmetric Gobo-Projector [GP] - max aperture angle
LED-FT-37W (4000K)
1442
80
electronic gear
18.08
139-2116_max
symmetric Gobo-Projector [GP] - max aperture angle
